Specifications

Dimensions

Overall Length	144.5 in (366 cm)
Overall Width	49 in (125 cm)
Overall Height (w/o Roof)	51 in (130 cm)
Overall Height (w/ Roof)	74.5 in (189 cm)
Wheel Base	99.5 in (253 cm)
Front Wheel Track	38.5 in (98 cm)
Rear Wheel Track	38.5 in (98 cm)
Ground Clearance	5.5 in (14 cm)

Power

Power Source	4 Cycle 24.5 cu in (401 cc)
Valve Train	Single Cylinder OHV
Fuel System	Electronic Fuel Injection
Horsepower/kW	13.5 hp (10.1 kW) Exceeds SAE J1940 Std
Electrical System	Starter/Generator - Solid State Regulator
Key/Pedal Start	Pedal
Air Cleaner	Replaceable Dry Cartridge
Lubrication	Pressurized Oil System
Cooling System	Air Cooled
Oil Filter	Spin-On
Fuel Capacity	5.2 Gallon (19.8 L) Tank
Speed Controller	N/A
Drivetrain	Continuously Variable Transmission (CVT)
Transaxle	Differential with Helical Gears (Gas Only)
Gear Selection	Forward-Reverse
Rear Axle Ratio	11.47:1 (Forward); 14.35:1 (Reverse)

Performance

Dry Weight	1090 lb (439 kg) (Without Batteries)
Curb Weight	1130 lb (528 kg)
Load Capacity	1200 lb (544 kg)
Outside Clearance	32.5 ft (9.9 m)
Speed	Up to 17 mph ± 0.5 mph (Up to 26 kph ± 0.8 kph)

Steering & Suspensions

Suspension	Leaf Springs with Hydraulic Shock Absorbers
Service Brake	Rear Wheel Mechanical Self-Adjusting Drum
Parking Brake	Self-Compensating, Single Point Engagement (Gas Only)
Tires	Paramount SBR Tire on 14” FTV Alloy Wheel

Body & Chassis

Frame	Welded Steel with E-Coat and DuraShield™ Powder Coat
Body & Finish	Injection Molded TPO

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
